Welding Helmet Böhler Guardian 50 voestalpine Böhler Welding

Welding Helmet Böhler Guardian 50 voestalpine Böhler Welding

✔ Automatic welding helmet Extremely robust, designed for the toughest working conditions.
✔ Grinding mode activated from the outside
✔ The true color cassette offers a perfect view of the weld

Welding Helmet Böhler Guardian 50



• Nylon shell
• Darkening cassette (4 protection levels)
• Low weight
• True - Colour - Technology
• Comfort headband



The Böhler Guardian 50 welding helmet can be used in many areas and features True - Colour - Technology for a true-color viewing experience. The Böhler Guardian 50 welding helmet has 4 sensors that detect the arc and automatically darken, as well as a nylon shell. The comfort headband can be adjusted in length and angle. The grinding mode can be activated by an external switch. Easy to use, even for inexperienced welders. Not suitable for laser welding.

The Böhler Guardian 50 welding helmet offers permanent protection against UV and infrared radiation and protects the face and eyes from welding sparks.

The welding helmet has a low weight of 480 grams.



Basic data

Manufacturer: Böhler

Product name: Welding Helmet Böhler Guardian 50

Material: Nylon shell

Size: Adjustable



Standard designation

CE 4/9 - 13 VA 1/1/1/2 EN379



Approvals

CE

EN379, EN175 B, EN166 B



Certification and Controls

Tested by: ECS – GmbH,

Test laboratory accredited by DAkkS D - PL - 19590 - 02 - 00



Preparation and Application

The helmet is delivered fully assembled and is ready for immediate use after only minor adjustments.

Bill of materials and assembly

Item	Number
Welding Helmet Böhler Guardian 50	32371
Outer protective lens	32423
Inner protective lens	32425
Lens holder with screws	32443
Sweatband	32416
Headband	32406
Diopter +1.0	32444
Diopter +1.5	32445
Diopter +2.0	32452
Diopter +2.5	32456
